Kanardia NESIS 7 Flight Display Kit with AD-AHRS-GPS
The Nesis model with the smallest display — 7 inches — is perfect for installations where the larger units simply don’t fit.
*A Lite version is also available, without maps and map-related functions.
NESIS is a cutting-edge navigation, flight, and engine monitoring system designed for ultralight airplanes, autogyros, and helicopters. It features a self-contained, state-of-the-art EFIS optimized for ultralight aircraft.
It is available in three sizes: 7", 8.4", and 10.1".
The 8.4" version features integrated buttons on the bezel, while the 7" and 10.1" models include the versatile Kliky control unit, which can be mounted anywhere for maximum convenience.
We take great care to design our instruments to be as lightweight and slim as possible.
KIT CONTENTS:
- NESIS 7" Touch Display
- Built-in AD-AHRS-GPS module
- Cables, GPS antenna, and OAT sensor on cable
- Engine monitoring system
Weight: 600g
Size: 175 x 109 x 42mm
Power: 720 mA
- EDITABLE LAYOUT
- Touchscreen, sunlight readable display, energy efficient, fast multicore processor, slim housing
- Personalised layout, logbook
- Flarm/ADS-B support, 3D terrain, multiple maps support, Wi-Fi support for METAR, map and software updates, USB tethering support for map and software updates, NMEA output
- Real-time engine monitoring, compatible with several engines (EMS)
- Radio support, integrated video output
- Pilot checklists
- Flight planning
- Traffic information
- ADS-B GDL 90 support
- External source connectivity
